Industrial Machinery Corporation was formed in the year 2011 and in just a span of 6 years; it has become a much respected name in the field of industrial machine manufacturing world. Since our formation in 2011, we have been busy working with full zeal and enthusiasm to retain and sustain the respect we have gained by designing and exporting only the finest quality machines to our clients ranging from not only India but abroad as well. Through the experience we have gained, we are now capable of designing and manufacturing a big range of machine and one such machine developed by us at our manufacturing base in Ludhiana is the PVC pipe threading machine. A PVC Pipe Thread Cutting Machine made at our manufacturing unit based at Ludhiana is one of the most famous machines and has its name for creating most accurate and precise threads on PVC pipes. When an order comes, we make sure that the finest quality is maintained at every step right from designing this machine on a paper to getting raw material to building it to packing and sending it to our buyers. All the raw material used for manufacturing this machine is derived from the best of resources and prior to getting into used, all the raw material is checked thoroughly by the quality supervision team for any sort of defect or flaw. If there is even a hint of defect fond, the raw material is declared unfit for use. Our PVC Pipe Thread Cutting Machine is specially programmed and better quality lathe which has the capacity to thread a PVC Pipe ranging from 50 M.M to 250 M.M for 3 meter or a 4 meter pipe. There is a newly designed collects system which makes that this machine assists the user to quickly upload and download of PVC pipes giving place to next slot of pipe for threading.
The best part of about this PVC pipe threading machine which makes this machine different and special from other PVC Pipe Thread Cutting Machine is that it is fitted with an advanced double-sided paddle the best part of this double sided saddle is that it allows two workers to work on it simultaneously in one time which means this machine has the capacity to produce twice the result in one time. The two users can work on PVC machine and thread PVC pipes from inside and outside in a single time. This machine has a hydraulic cylinder lead screw box nut engaging, one hydraulic pipe clamping cylinder and one hydraulic cylinder for die-head opening with micro switches with automation with control panel. With all these power-packed features, there is an unconditional guarantee that this machine is made to perform at the best of its capability to produce precise and accurate pipe threading results. Our PVC pipe threading machine is designed and customized as per the prerequisite and specifications mentioned by the clients. We make every possible effort to make our PVC Pipe Thread Cutting Machine as comfortable as possible. Mentioned below are the names of few cuts that our PVC pipe threading machine can cut:
Listed below are the names of various parts of PVC pipe threading machine that we manufacture at our manufacturing base located in Ludhiana:
| Model | 3/8" to 2" | 1/2" to 3" | 1" to 4" | 2.½" to 6" | 4" to 8" | 8" to 10" |
| Saddle Movement | 10" - 12" | 16" | 10" – 12" | 8" | 8" | 8" |
| Spindle Speed Range | 127-180 | 60-90-120 | 40-75-115 | 25-50 | 25-50 | 10-20-30 |
| Number of Spindle Speed | 2 | 3 | 3 | 2 | 2 | 3 |
| Threading Capacity | 3/8" to 2" | 1/2" to 3" | 1" to 4" | 2.1/2" to 6" | 4" to 8" | 8" to 10" |
| Production per Hour | 100-120 | 70-90 | 35-40 | 20-25 | 15-20 | 15-20 |
| H.P. Required | 3 H.P. | 7.5 H.P. | 12.5 H.P. 960 | 15 H.P. 960 | 20 H.P. 960 | 30 H.P. 960 |
| Lead Screw | Provided | Provided | Provided | Provided | Provided | Provided |
| Weight (KG) Approx. | 550 | 990 | 1600 | 1900 | 2500 | 5000 |
PVC Pipe Threading Machine Tangential Chaser
IMC Tangential Chasers are manufactured from imported High Speed Steel which must pass exacting metallurgical standard. Experienced heat treatment with the automatic imported heat treatment plant and imported Testing equipment's, assures that they will perform satisfactorily in service and produce quality threads within the tolerance for which they ware intended.
IMC Chaser are interchangeable. If one Pc. of a chaser set is damaged & is beyond use. Then same No. pc. Of the other chaser set lying in stock may be used and there will not be any difference in threading performance and the damaged set can be replaced without the necessity of replacing entire set.
View Lanco Type Threading ChasersThe pipe must be held without unacceptable deformation, and the cutting tools must suit the material and thread. Share the actual pipe dimensions for review.
Include PVC grade, wall thickness and joint drawing, the finished component drawing and the quantity you intend to produce. These details help IMC review the machine and tooling together.
PVC threads are cut with holding and tooling appropriate to the plastic pipe wall and joint.
